VDWall VF2000 Multi-window LED Video Wall Panels Processor

VDWall
VDWALL-VF2000
In stock
$10,522.00
VDWall VF2000 Multi-window LED Video Wall Panels Processor Features: 1. Faroudja® Real Color® Picture processing,10+ Bit Faroudja® DCDI Cinema Processing and Faroudja® TureLife™ Video image enhancement 2.Advanced interlaced...

VDWall VF2000 Multi-window LED Video Wall Panels Processor Features:

1. Faroudja® Real Color® Picture processing,10+ Bit Faroudja® DCDI Cinema Processing and Faroudja® TureLife™ Video image enhancement

2.Advanced interlaced motion image adaptive processing technology to eliminate video image movement tail and saw-tooth phenomenon

3.Plug-in design for more flexible and convenient hardware maintenance

4.Redundant power supply design, equipment operation more stable and reliable

5.CrossPoint fully cross-high bandwidth video switching technology

6.Support mixed video seamless switching technology, no black screen between image signals switching

7.Whole procedure 60Hz RGB format signal processing and transmission,without reducing image quality and frame rate,perfect image and color reproduction

8.Support functions like input text overlay,input signal remark and etc

9.Support signal sources preview function, support real-time preview of all input signal sources

10.AIAO(Any In Any Out)function,any input crop and any output

11.Using advanced sync-frame splicing technology, high-speed images are completely synchronized without tearing image

12.Support multiple SD、HD、analog and digital input

13.16×CVBS 16×VGA

16×DVI(HDMI) 16×SDI(SD-SDI / HD-SDI / 3G-SDI)

14.The quantity of supported input signal is up to 64,  the supported function for any input signal includes opening window , roam , scale , free overlay, etc. it can process 32 signals at the same time, and it can display 32 different images at most

15.Maximally 16 preset display modes,switch and select seamlessly

16.Standard VESA DVI output, compatible with mainstream full-color control systems

17.16 DVI outputs, maximum output resolution 1920*1080_60Hz

18.single unit splicing output width up to 20480 pixels or output height up to 9600 pixels

19.Any input signals seamless switching and Fade-in/Fade-out switching

20.Support RS232 serial port, USB and TCP/IP control, open control protocol, easy integration with various control systems

21.PC software is easy to use,  any open window , roam, overlay

22.Backup or Restore the device settings and adjustment data by a PC

23.24/7 Application, stable and reliable



Rental Performance,special-shaped or ultra-large LED display,mixed displays(with different poxel potch),Stage Entertainment & Theater,High-end meeting & Exhibitons etc.



Connection Diagram









VDWall VF2000 Multi-window LED Video Wall Panels Processor



VDWall VF2000 Multi-window LED Video Wall Panels Processor Parameter:



Input signal
Type/Quantity 16×CVBS
16×VGA(RGBHV)

16×DVI

(VESA/ CEA-861)

16×SDI

(SDI/HD-SDI/3G-SDI)

Composite Video format PAL/NTSC
Composite Video 1V(p_p)/ 75Ω
Scope Impedance
VGA format  PC(VESA) ≤1920×1200_60Hz
VGA Scope Impedance

RGB = 0.7 V

(p_p)/ 75Ω

DVI format PC(VESA)

≤1920

×1200_60Hz

HDMI-1.3

(CEA-861)

≤1920

×1080_60Hz

SDI format SMPTE259M-C 480i_60Hz
SMPTE 292M 576i_50Hz
SMPTE 274M/296M

720p、

1080i、

1080p

SMPTE 424M/425M
Input port CVBS:VGA socket P4

VGA:15pin

D_Sub(female)

DVI:24+5 DVI_I
SDI:BNC/ 75Ω
Output signal
Type/Quantity 16×DVI
DVI format  1920×1080p_60Hz
Output port DVI:24+5 DVI_I
Others
Control port RS232/USB/LAN
Input Voltage 100-240VAC 50/60Hz
Maximum power ≤500W
consumption
Environmental temperature 0-45 ℃
Environmental humidity 15-85%
Dimensions

482.6(L) x

441.5(W) x 266(H)mm

(Product)
Dimensions

620(L) x

565W) x 455(H)mm

(Package)



Download

VDWALL VF2000 Introduction (Chinese)
