Product overview
The Sysolution KD05 is a compact MCU card for small full-color LED display projects. Its original feature list describes five scan-address signals, a key-reset function and an adjustable clock frequency for configuring supported LED modules.
Product specifications
| Parameter | Specification |
|---|---|
| Model | KD05 |
| Product type | Compact MCU LED display card |
| Scan-address signals | A, B, C, D and E |
| Reset function | Key reset supported |
| Listed clock-frequency range | 80 MHz to 240 MHz, adjustable |
| Applications described | Full-color storefront signs, taxi animation signs, backpack displays, vehicle sticker displays, stall signs, creative displays and motorcycle signs |
Selection and installation
The 80–240 MHz value is the clock-frequency range stated in the original feature list. It is not an LED refresh-rate specification.
Five scan-address signals do not establish compatibility with every module or a particular maximum scan ratio. Check the module pinout, driver IC, firmware and load requirements before wiring.
The original download URL is retained, but it currently returns 404 Not Found. The available product text does not establish input voltage, current, board dimensions or maximum pixel capacity; these parameters are not inferred from the images or model name.
Product images and video



Frequently asked questions
1. What type of LED projects is KD05 described for?
The original list includes compact full-color storefront, taxi, backpack, vehicle, stall, creative and motorcycle displays. Confirm the requirements of the actual modules.
2. Which scan signals are listed?
A, B, C, D and E scan-address signals are listed, along with a key-reset function.
3. Is the 80–240 MHz figure the screen refresh rate?
No. The original information labels it as an adjustable clock frequency, without specifying the LED refresh rate.
4. Are the voltage and maximum pixel load confirmed?
They are not provided in the available product text. The retained specification download currently returns 404, so obtain matching KD05 documentation before final selection.
Download specification
Sysolotion KD05 LED display Small size MCU card Specification
