Mooncell MVP601-D / MVP125-D / V2 LED Video Splicers
Price range: $ 107.00 through $ 743.00
Mooncell MVP601-D, MVP125-D and V2 LED video splicer options. This series listing includes DVI, HDMI, VGA and CVBS input information plus optional 3G-SDI. Check the selected model manual for its exact configuration.
Mooncell MVP601-D, MVP125-D and V2 video splicers
This page groups three Mooncell LED video splicer models. Select the required model and use its own manual to verify the input configuration and signal support before ordering.
Input information from the original series listing
The original page supplies the following input summary without assigning each row to an individual model. These values should be checked against the selected model manual rather than assumed to apply identically to all three options.
| Parameter | Specification |
|---|---|
| DVI video input | Quantity: 2; DVI socket; DVI 1.0, backward compatible with HDMI 1.3; VESA PC up to 1920×1200, HD up to 1080P |
| HDMI video input | Quantity: 3; HDMI socket; DVI 1.0, backward compatible with HDMI 1.3; VESA PC up to 1920×1200, HD up to 1080P |
| VGA video input | Quantity: 3; DB15 socket; VESA PC up to 1920×1200 |
| VGA signal values as originally listed | R, G, B, Hsync, Vsync: 0 to 1vpp ±3dB (0.7V Video + 0.3V Sync); 75 ohm; black level: 300mV; Sync-tip: 0V |
| Composite CVBS input | Quantity: 4; BNC; PAL/NTSC; 480i, 576i |
| CVBS signal notation as originally listed | 1vpp ±3d8 (0.7V Video + 0.3V Sync), 75 ohm |
| Optional 3G-SDI input | Quantity: 1; BNC; SD-SDI, HD-SDI, 3G-SDI |
| Listed SDI formats | 1080p 60/50/30/25/24/25(PsF)/24(PsF); 720p 60/50/25/24; 1080i; 1035i; 625/525 line |
The original CVBS signal notation contains “3d8”; its intended unit has not been confirmed. Refer to the matching manual for analog signal tolerances.
Product images
Specification downloads
Mooncell MVP601-D Full Color LED Video splicer series manal
Mooncell V2 Video splicer series manual
Mooncell MVP125-D Video splicer series manual
Frequently asked questions
1. Which models can I select on this page?
The listing groups MVP601-D, MVP125-D and V2. Confirm the chosen option before placing an order.
2. Are the input quantities identical on all three models?
The original series summary does not identify the model for each input row. Use the separate model manuals to confirm the actual ports.
3. Is 3G-SDI a standard input?
The original input description labels 3G-SDI as optional. Confirm that the selected unit includes the required option.
4. Which manual should I download?
Download the file labeled for your selected model: MVP601-D, MVP125-D or V2. All three original links are retained above.
