VDWall LVP605S LED Video Processor – SDI / HD-SDI
$ 420.00
VDWall LVP605S LED video processor with SDI/HD-SDI expansion, video scaling, PIP/POP and text overlay. Sending cards are optional.
10000 in stock
VDWall LVP605S LED Video Processor with SDI Input
The LVP605S scales and switches video for LED displays and uses the SDI/HD-SDI expansion option in the LVP605 series. It supports seamless and fade switching, picture-in-picture layouts, text/logo overlay, picture freeze and AIAO cropping.
Product parameters
| Item | Listed specification |
|---|---|
| Base input types | 3 × CVBS; 1 × DVI; 1 × HDMI; 2 × VGA; 1 × YPbPr/YCbCr; 1 × S-Video |
| Expansion for S model | SDI / HD-SDI |
| HDMI | HDMI 1.3a with HDCP; HD 1080p input |
| Single-unit output in original listing | 2048 × 1152 |
| PIP/POP presets in original listing | 4 custom modes |
| Sending card installation | Space for 2 LED sending cards; cards optional |
| Processing | 10-bit processing; Faroudja DCDI, Real Color and TrueLife |
Check the installed expansion board, supported timing and manual revision. LVP605D uses a different DVI/VGA/HDMI expansion module; these options should not be treated as simultaneous standard inputs.
VDWALL LVP605S Video Controller Specification
Frequently asked questions
1. What distinguishes LVP605S from LVP605D?
The S version uses SDI/HD-SDI expansion; the D version uses DVI/VGA/HDMI expansion.
2. Does it include LED sending cards?
The listing provides installation capacity for two cards and states that sending cards are optional. Confirm package contents.
3. Can LVP605S overlay text on video?
Yes. Text, graphics and logo overlay are listed functions.
4. Which resolution should I use?
Match the source, processor revision and receiving system. The table identifies the original listing’s output figure; check the matching manual before setup.
| Weight | 7 kg |
|---|
