MEAN WELL HSP-200-5 5V 40A 200W LED Sign Power Supply
$ 32.00
MEAN WELL HSP-200-5 5V 40A 200W LED sign supply with active PFC, 90–264VAC input and a 210 × 62 × 31mm case. Original images and specification PDF retained.
9996 in stock
MEAN WELL HSP-200-5 5V 40A 200W LED Sign Power Supply
The MEAN WELL HSP-200-5 is a 5V 40A power supply for LED signs and display cabinets. Its 200W output, active PFC and narrow 62mm case suit low-voltage display installations that need a compact supply with full-range AC input.
Product parameters
| Parameter | Specification |
|---|---|
| Model | HSP-200-5 |
| Rated output | 5V, 40A, 200W |
| Voltage adjustment | 4.5–5.5V |
| AC input | 90–264VAC |
| Typical efficiency | 88.5% |
| Power factor correction | Built-in active PFC |
| Rated cooling condition | Natural air convection |
| Dimensions (L × W × H) | 210 × 62 × 31mm |
| Board protection | Conformal coating |
Allow for input-voltage and temperature derating when sizing the load. Check the PDF for terminal connections and final equipment EMC requirements.
Product images and documents
Meanwell HSP-200-5 LED Sign Power Supply Specification
Frequently asked questions
1. What output does the HSP-200-5 provide?
It supplies nominal 5V DC at up to 40A, with a rated power of 200W. The adjustment range is 4.5–5.5V.
2. Does the HSP-200-5 support 115V and 230V mains?
Its specified AC input range is 90–264VAC. Check the input derating curve when operating near the lower end of the range.
3. How much cabinet space does it need?
The supply measures 210 × 62 × 31mm. Allow additional room for terminals, wiring and ventilation according to the installation instructions.
4. Can conformal coating replace a weatherproof cabinet?
No. Conformal coating is a board-protection feature, not an enclosure waterproof rating. An outdoor sign still needs suitable protection for the supply and connections.
| Weight | 1.6 kg |
|---|
