NovaStar TU15 Pro LED Playback Control Processor
Price range: $ 573.00 through $ 661.00
NovaStar TU15 Pro combines Android 11 media playback and LED sending functions for indoor screens up to 2.6 million pixels. Connect HDMI sources, play USB content or mirror a compatible device wirelessly.
4 Ethernet outputs · 2 HDMI 1.3 inputs · 3 USB 2.0 ports. Choose the processor alone or the option with a PTB1304 screen-mirroring dongle.
NovaStar TU15 Pro: playback and LED control in one device
The NovaStar TU15 Pro is an Android-based LED playback control processor for indoor LED displays. It combines a media player and sending-card functions, with four Ethernet outputs and a total capacity of 2.6 million pixels. Use it for presentation screens in meeting rooms, classrooms, exhibition spaces and hotel lobbies.
Selection essentials: two HDMI inputs connect external sources; USB playback supports local content; wireless mirroring supports Windows, macOS, iOS and Android. Check your screen’s pixel dimensions and receiving-card compatibility before ordering.
TU15 Pro specifications
| LED loading capacity | Up to 2,600,000 pixels across the device |
|---|---|
| LED outputs | 4 × Gigabit Ethernet (RJ45) |
| HDMI inputs | 2 × HDMI 1.3; standard maximum input 2048 × 1152 at 60 Hz; custom timings require configuration |
| USB connections | 3 × USB 2.0 for media playback and peripherals |
| Maximum scaled dimensions | 4096 pixels wide or 1920 pixels high, subject to the total 2.6-million-pixel limit |
| HDMI output | 1 × HDMI output for standard 1080p video |
| Audio outputs | 1 × 3.5 mm audio; 1 × SPDIF digital audio |
| Operating system | Android 11 |
| Memory and storage | 4 GB RAM; 32 GB internal storage |
| Control connections | Ethernet control, RS232 and sensor connector |
Resolution matters: the maximum width and height are separate limits. A 4096 × 1920 canvas is 7,864,320 pixels and exceeds this controller’s capacity. A 1920 × 1080 screen has 2,073,600 pixels and fits the total pixel budget, subject to receiving-card mapping and port loading.
HDMI, USB playback and wireless presentations
- HDMI sources: connect a computer or other compatible source for live presentations. Match the source timing to the supported input configuration.
- Local playback: use USB media or internal storage for content without leaving a presentation computer connected. FAT32 and NTFS USB drives are supported; exFAT and FAT16 are not supported.
- Wireless mirroring: share content from supported Windows, macOS, iOS and Android devices. The connection method and available features depend on the device, app and firmware.
- Everyday control: use the remote or ViPlex Handy for playback and screen control. VNNOX Care supports screen configuration and monitoring.
- Display adjustment: image enhancement and selectable display modes help adapt documents, video and meeting content to the screen.
4K decoding is not 4K LED output. The TU15 Pro can decode supported H.264/H.265 4K media, but the LED screen remains limited to 2.6 million pixels. Do not treat the decoding specification as support for a native 3840 × 2160 LED canvas or a standard 4K HDMI input.
Choose your TU15 Pro package
Select Novastar TU15 Pro for the processor option, or Novastar TU15 Pro with PTB1304 Screen Projector for the option with the wireless mirroring dongle. The PTB1304 is an optional accessory, not part of the processor-only option. Confirm the required adapter and source-device connection when selecting the dongle package.
The current price for each option appears in the selector above. For quantities, shipping or compatibility advice, contact EagerLED with your screen resolution, receiving-card model, input sources and delivery country.
Check screen compatibility before ordering
- Calculate total screen pixels: width in pixels × height in pixels.
- Confirm the total load, maximum dimensions and distribution across the four Ethernet outputs.
- Identify the installed receiving cards and request confirmation of the intended screen configuration.
- Choose HDMI, USB playback or wireless mirroring, then confirm any required accessories.
For a larger pixel load, compare the NovaStar TU20 Pro. Browse NovaStar LED control products for other system requirements.
Product images and specification download
Download the TU15 Pro specifications PDF (V1.0.1). This retained download is an earlier document revision. Software features and configuration ranges may differ with firmware; confirm the applicable version for your project.
Frequently asked questions
Can the TU15 Pro display a native 4K LED canvas?
No. A 3840 × 2160 LED canvas contains 8,294,400 pixels, exceeding the 2.6-million-pixel load limit. Supported 4K media decoding does not increase that limit.
Does the processor-only option include the PTB1304?
No. Select the option explicitly named “with PTB1304 Screen Projector” if you need that accessory, and confirm its connection requirements before ordering.
Can it play content without a computer?
Yes. Local USB playback and internal media storage allow standalone playback. Initial screen configuration and supported media formats still need to be checked.
Need a compatibility check? send your screen specifications.
