Product overview
The Linsn L4 is a synchronous/asynchronous LED player with HDMI input, USB flash-drive playback and LAN program playback. It supports Wi-Fi, hotspot and Ethernet transfer, with 4G identified as optional in the linked V2.1 manual. Confirm the pixel-loading mode because the manual’s total capacity and individual output descriptions differ.
Product specifications
| Parameter | Specification |
|---|---|
| Model / manual | L4; V2.1, March 2019 |
| Display modes | Synchronous / asynchronous |
| Capacity in overview and feature list | Up to 1.3 million pixels |
| LED OUT / BACK UP descriptions | 650,000 pixels each; one output and one backup connection |
| Video input | HDMI IN |
| Playback | USB flash drive and LAN |
| Transfer | Wi-Fi, hotspot, Ethernet; optional 4G |
| Sensor support | Temperature and brightness interfaces |
| Audio | 3.5 mm output |
| Power input / consumption | 12 V; 20 W |
| Operating conditions | −20°C to +75°C; 0–95% humidity |
| Weight | 0.65 kg |
Check output mode and required accessories
The manual states 1.3 million pixels overall but identifies LED OUT and BACK UP at 650,000 pixels each. It does not explain a mode that reconciles those figures. Confirm usable screen capacity and backup operation for the supplied version rather than adding the ports as independent display area.
The original listing mentions HDMI output, but the attached V2.1 interface table lists HDMI input only. Verify the physical hardware if HDMI output is required.
Confirm the 4G module, antennas and sensors separately. Test your content and source signal before deployment; broad format support does not establish every codec or input timing.


Frequently asked questions
1. Can L4 use both HDMI and stored programs?
Yes. It is documented as a synchronous/asynchronous player with HDMI input and USB flash-drive or LAN playback.
2. Is the usable L4 load 1.3 million or 650,000 pixels?
The manual states 1.3 million overall but describes 650,000-pixel LED OUT and BACK UP ports. Confirm the supported mode and capacity with the exact unit; backup is not automatically extra display area.
3. Does every L4 include 4G?
No. The linked manual identifies 4G as optional. Confirm cellular hardware and service requirements for the supplied configuration.
4. Does the L4 manual confirm HDMI output?
The original listing says HDMI input/output, but the V2.1 interface list documents HDMI IN only. Confirm the hardware if an HDMI output is required.
