Huidu HD-D05 Wi-Fi LED Controller – Text, Images & Animation
Original price was: $ 33.00.$ 25.00Current price is: $ 25.00.
Huidu HD-D05 is an asynchronous LED controller with four HUB75E ports, Wi-Fi/USB updates and 128 MB program storage. It supports a listed 640 × 64 control range for text, images and animation. Video playback is not supported.
1000 in stock
Huidu HD-D05 asynchronous LED controller for small signs
The HD-D05 stores and plays text, graphics, clocks and supported animation on a full-color LED screen. Four HUB75E interfaces connect matching modules, and Wi-Fi or USB allows programs to be updated through HDPlayer or LedArt.
This model does not support video playback. Its content functions are intended for graphics and message-based programs.
HD-D05 technical specifications
The table follows the linked V2.0 specification.
| Control range | 640 × 64 pixels |
|---|---|
| Maximum width / height | 640 pixels / 128 pixels; confirm valid layout within the control range |
| LED module connections | 4 × HUB75E |
| Scan / grayscale | Static to 1/64 / 256–65,536 |
| Video playback | Not supported |
| Animation / image formats | SWF, GIF / BMP, JPG, JPEG, PNG |
| Storage | 128 MB onboard; USB storage expansion supported |
| Communication / software | Wi-Fi and USB drive / HDPlayer and LedArt |
| Power supply | 5 V recommended; rated range 4.2–5.5 V |
| Storage temperature | −40°C to 105°C |
| Operating-temperature entry | PDF °C row lists −40°C to 80°C but is labelled humidity; confirm intended rating |
| Operating humidity | 0–95% in the separate percentage row |
Program and installation planning
Supported effects include word art, animated backgrounds, neon-style display and counters. Sensor-related functions require compatible external accessories. Match module wiring and scan mode before configuration, and use the specified 5 V supply recommendation.
The PDF has a unit/label mismatch in the apparent operating-temperature row: it uses °C with −40/25/80 values but calls the row humidity. Confirm that rating if the installation depends on temperature limits.
HD-D05 frequently asked questions
Does Huidu HD-D05 play video?
No. The V2.0 specification explicitly states that video playback is not supported. Use the documented text, image, SWF/GIF animation, clock and display-effect functions.
What display size is specified for D05?
The listed control range is 640 × 64 pixels, with maximum width 640 and height 128. These separate limits do not establish a full 640 × 128 canvas; verify the actual module layout and scan mode.
Can I update the D05 from a phone?
The document lists LedArt mobile control over Wi-Fi. HDPlayer is the computer software, and USB storage provides another program-update method.
Can the D05 play without keeping a computer connected?
Yes. It stores program files in 128 MB onboard memory for offline playback. USB storage expansion is supported, but the document’s “unlimited” wording should not be read as a guaranteed unlimited drive capacity.
Which sensors and tests are available?
The card has temperature and external-sensor ports, with temperature/humidity and adaptive-brightness functions listed. Use matching sensor accessories. Its test button checks display brightness and contrast, while running and power indicators show operating status.
Specification download
| Weight | 0.4 kg |
|---|
