MEAN WELL ELG-300-24A 24V LED Driver, Up to 300W
$ 46.00
24V LED driver delivering up to 300W at 200–305VAC, with a 255W rating at 100–180VAC. Internal voltage/current adjustment and IP67 housing.
10000 in stock
MEAN WELL ELG-300-24A 24V LED Driver, Up to 300W
The MEAN WELL ELG-300-24A is a 24V LED driver with constant-voltage and constant-current operating modes. Its output rating depends on mains voltage: 300W at 200–305VAC input and 255W at 100–180VAC input. Internal potentiometers provide output adjustment.
Product parameters
| Parameter | Specification |
|---|---|
| Model | ELG-300-24A |
| Nominal output voltage | 24V |
| Output at 200–305VAC input | 12.5A, 300W |
| Output at 100–180VAC input | 10.63A, 255W |
| Constant-current region | 14.4–24V |
| Voltage adjustment | 22.4–25.6V |
| Current adjustment | 6.25–12.5A |
| AC input range | 100–305VAC |
| Typical efficiency | 94% |
| Enclosure rating | IP67 |
| Dimensions (L × W × H) | 246 × 77 × 39.5mm |
Use the static-characteristic curve for input voltages between the listed rating bands. Also apply temperature derating; 300W is not available across the entire input range.
Product images and documents
Meanwell ELG-300-24A LED Lighting Power Supply Specification
Frequently asked questions
1. Can ELG-300-24A deliver 300W on 115V mains?
The specification lists 255W and 10.63A for 100–180VAC input. The 300W, 12.5A rating applies at 200–305VAC.
2. What output settings can be adjusted?
The voltage adjustment range is 22.4–25.6V, and the current adjustment range is 6.25–12.5A. The permitted load still depends on input and temperature conditions.
3. Is this driver constant voltage or constant current?
It supports both modes, with a nominal 24V output and a 14.4–24V constant-current region. Check the LED load against the operating curve.
4. What should I check when replacing an ELG-300 supply?
Confirm ELG-300-24A on the label, the mains voltage, load current, mounting dimensions and wiring. Use the PDF to check derating and the correct output setting.
| Weight | 1.6 kg |
|---|
