MEAN WELL LPV-60-12 / LPV-60-24 60W Power Supply
$ 10.00
60W constant-voltage supplies: LPV-60-12 delivers 12V 5A; LPV-60-24 delivers 24V 2.5A. Both feature 90–264VAC input and an IP67 encapsulated plastic enclosure.
MEAN WELL LPV-60-12 / LPV-60-24 60W Power Supply
The MEAN WELL LPV-60-12 and LPV-60-24 are constant-voltage supplies for compatible LED decoration and advertising equipment. Both provide 60W, with separate 12V and 24V versions in an encapsulated, insulated plastic case.
Product parameters
| Parameter | Specification |
|---|---|
| LPV-60-12 output | 12V, 5A, 60W |
| LPV-60-24 output | 24V, 2.5A, 60W |
| AC input | 90–264VAC |
| Typical efficiency | 83% (12V); 86% (24V) |
| Output design | Constant voltage |
| Enclosure | Fully encapsulated plastic case, IP67 |
| Cooling | Natural air convection |
| Dimensions (L × W × H) | 162.5 × 42.5 × 32mm |
Choose the voltage version required by the load. IP67 applies to the supply enclosure; wiring joints and the finished installation need appropriate protection. Review the PDF application restrictions, including suitability for lighting use in the EU.
Product images and documents
Meanwell LPV-60-12 / LPV-60-24 Lighting Power Supply Specification
Frequently asked questions
1. How do LPV-60-12 and LPV-60-24 differ?
The LPV-60-12 supplies 12V at up to 5A; the LPV-60-24 supplies 24V at up to 2.5A. Both are rated at 60W.
2. Can one unit switch between 12V and 24V output?
These are separate fixed-voltage models. Order the model that matches the connected LED equipment.
3. Is the LPV-60 a constant-current LED driver?
It is a constant-voltage power supply. Use it with a load designed for its 12V or 24V output rather than assuming it directly regulates an arbitrary LED string’s current.
4. Does IP67 also protect the wiring connections?
The supply is encapsulated to IP67, but exposed cable joints are separate parts of the installation. Protect and connect them according to the application and installation instructions.
