Colorlight H16F-N Fiber Transceiver | 16 Neutrik Ethernet Ports
$ 2,300.00
Colorlight H16F-N fiber transceiver with 16 Neutrik gigabit Ethernet ports and two 10 Gb/s fiber interfaces. Uses single-mode twin-core fiber and full-duplex LC connectors. The 20 km optical module is optional; the specification also lists a 1 km module.
10000 in stock
H16F-N fiber transmission for LED video walls
The Colorlight H16F-N provides 16 Neutrik gigabit Ethernet connections and two 10 Gb/s fiber interfaces for LED control-system transmission. Its single-mode twin-core optical connection uses full-duplex LC connectors. The specified module options are 1 km and an optional 20 km.
Technical specifications
| Parameter | Specification |
|---|---|
| Ethernet interfaces | 16 Neutrik gigabit Ethernet ports |
| Fiber interfaces | 2 × 10 Gb/s |
| Listed data-link rate | 20 Gb/s |
| Optical mode / cable | Single-mode twin-core fiber |
| Fiber connector | Full-duplex LC |
| Module distance options | 1 km; 20 km optional |
| Laser | DFB |
| Power input | AC 100–240 V |
| Operating temperature | 0 to +70 °C |
| Storage temperature | −40 to +85 °C |
Optical module and system selection
The specification includes a connection diagram with the Colorlight Z6. Confirm the exact sender, optical modules and Ethernet port mapping before selecting the transmission arrangement. A longer-distance module is a separate option; check the supplied module labels and fiber route.
Green indicators show fiber-port and Ethernet-port working status. The specification lists hot-pluggable optical modules, but module compatibility still needs to be checked for the installed system.
Product photos
Specification download
Download the H16F-N specification (V1.0)
Frequently asked questions
How many network and fiber ports does H16F-N have?
The V1.0 specification lists 16 Neutrik gigabit Ethernet ports and two fiber ports with 10 Gb/s bandwidth per fiber port.
Does H16F-N support a 20 km fiber link as standard?
The specification lists a 1 km fiber module and an optional 20 km fiber module. Confirm which modules are supplied; the 20 km option should not be assumed for every unit.
What fiber cable and connector are required?
H16F-N is specified for single-mode twin-core fiber with a full-duplex LC connection. Match the optical modules, connector and link requirements at both ends.
Is each Ethernet port rated at 20 Gb/s?
No. The Ethernet ports are gigabit ports. The document lists a 20 Gb/s data-link figure together with two 10 Gb/s fiber interfaces.
What power supply does the H16F-N use?
The specified input is AC 100–240 V. The linked document does not provide a rated power-consumption value, so voltage should not be presented as wattage.
| Weight | 5 kg |
|---|
